***PURCHASE FROM GA STOCKCODE BLR8620*** FUSION BLADE EXTRA HIGH LIFT

Genuine BigDog & HUSTLER 60" Cut Side Discharge Extra High Lift Notched Fusion BarBlade

Genuine Hustler and BigDog extra high lift notched bar blade. Fitted as a servicereplacement blade on the models listed below where an extra high lift blade isrequired. Blade Lift refers to the ability of a blade to provide vacuum to liftgrass so that it can be cut uniformly. More blade lift also contributes to removingdebris out of the grass, clearing debris out of the deck and throwing the grassfurther in side discharge mode. In some conditions, more blade lift can result incausing debris to build up under the deck, while in other conditions, the oppositeis true. Blade "Lift" can be measured from the bottom side of the blade to thehighest point of the blade sail. An extra high lift blade (EHN) provides liftrequired for high velocity style decks. Blade lift for this blade measures 1.20"(30.48 mm). Fusion blades feature an exclusive electro-fusion technology thatcreates an ultra-hard layer at the blade’s cutting edge, the blade remains sharpand continues to give a clean cut far longer than any blade on the market.

BigDog 602771HUSTLER 602771

0.63"

16.002 mm

60" cut

1524 mm

152.4 cm

20.50"

520.7 mm

0.25"

6.35 mm

3"

76.2 mm

Flute/sail height 1.20"

Flute/sail height 30.48 mm

Round

60" (1524 mm) cut BigDog Diablo MP (model BDU937292EX) side discharge zero turnradius (ZTR) models.

3

60" (1524 mm) cut HUSTLER ATZ (model HU931915EX), Super Z EFI SD (modelHU934927EX), Super Z HD SD (models HU935254EX, HU940551EX and HU941310EX), Super ZSD (models HU929935EX, HU932160EX, HU938118EX, HU938886EX and HU941146EX), Super ZHyperdrive SD (model HU937060EX), Super Z Hyperdrive EFI SD (model HU937003EX),X-One (models HU932723EX, HU934174EX, HU934836EX, HU936799EX and HU941120EX) and ZDiesel SD (models HU931204EX, HU932673EX and HU938183EX) side discharge zero turnradius (ZTR) models

3

Extra high lift, notched, flat, Fusion blade, clockwise rotation (flute/sail height1.20"/ 30.48 mm).

1

Please call our friendly sales team if any assistance or further information isrequired.

All blade bars are sold as singles, order the quantity required to make up a set.

BigDog, HUSTLER

Bar Blade, Blade Bar, Extra High Lift Bar Blade,
