***PURCHASE FROM GA STOCKCODE BLR8544*** FUSION BLADE HIGH LIFT,

Genuine HUSTLER 72" Cut Side Discharge High Lift Fusion Bar Blade

Genuine Hustler high lift Fusion bar blade. Fitted as a service replacement bladeon the models listed below where a high lift blade is required. Blade Lift refersto the ability of a blade to provide vacuum to lift grass so that it can be cutuniformly. More blade lift also contributes to removing debris out of the grass,clearing debris out of the deck and throwing the grass further in side dischargemode. In some conditions, more blade lift can result in causing debris to build upunder the deck, while in other conditions, the opposite is true. Blade "Lift" canbe measured from the bottom side of the blade to the highest point of the bladesail. The high Lift Blade (H) is the standard blade for many deep decks. A highlift blade provides more vacuum for better finished apperance. Blade lift for thisblade measures 1.09" / 27.68 mm). Fusion blades feature an exclusive electro-fusiontechnology that creates an ultra-hard layer at the blade’s cutting edge, theblade remains sharp and continues to give a clean cut far longer than any blade onthe market.

HUSTLER 798702

0.63"

16.002 mm

72" cut

1829 mm

182.9 cm

24.50"

622.3 mm

0.203"

5.156 mm

3"

76.2 mm

Flute/sail height 1.09"

Flute/sail height 27.68 mm

Round

72" (1829 mm) cut HUSTLER Super Z (model HU932152EX), Super Z EFI (modelHU934950EX), Super Z HD (models HU940577EX and HU941344EX), Super Z Hyperdrive(model HU937086EX), Super Z Hyperdrive EFI (model HU937037EX), Z Diesel (modelsHU931238EX, HU932699EX and HU938225EX) and 3700 (model HU928713EX) side dischargezero turn radius (ZTR) models.

3

High lift, flat Fusion blade, clockwise rotation (flute/sail height 1.09"/ 27.68mm). Fusion blades feature an exclusive electro-fusion technology that creates anultra-hard layer at the blade’s cutting edge, the blade remains sharp andcontinues to give a clean cut far longer than any blade on the market.

1

Please call our friendly sales team if any assistance or further information isrequired.

All blade bars are sold as singles, order the quantity required to make up a set.
