***PURCHASE FROM GA STOCKCODE BLR8544*** FUSION BLADE EXTRA HIGH LIFT (Sold per blade)

Genuine HUSTLER 72" Cut Side Discharge Extra High Lift Notched Fusion Bar Blade

Genuine Hustler extra high lift notched Fusion bar blade. Fitted as a productionline blade on 72" cut side discharge HUSTLER Super Z & Super Z HD models. Fitted asa service replacement blade on the other models listed below where an extra highlift blade is required. Blade Lift refers to the ability of a blade to providevacuum to lift grass so that it can be cut uniformly. More blade lift alsocontributes to removing debris out of the grass, clearing debris out of the deckand throwing the grass further in side discharge mode. In some conditions, moreblade lift can result in causing debris to build up under the deck, while in otherconditions, the opposite is true. Blade "Lift" can be measured from the bottom sideof the blade to the highest point of the blade sail. An extra high lift blade (EHN)provides lift required for high velocity style decks. Blade lift for this blademeasures 1.20" (30.48 mm).Fusion blades feature an exclusive electro-fusion technology that creates anultra-hard layer at the blade’s cutting edge, the blade remains sharp andcontinues to give a clean cut far longer than any blade on the market.

HUSTLER 602857

0.63"

16.002 mm

72" cut

1829 mm

182.9 cm

24.50"

622.3 mm

0.25"

6.35 mm

3"

76.2 mm

Flute/sail height 1.20"

Flute/sail height 30.48 mm

Round

72" (1829 mm) cut HUSTLER Super Z (models HU932152EX and HU929950EX), Super Z HD(models HU935338EX, HU940577EX, 941344EX,), Super Z Hyperdrive (model HU937086EX),Super Z Hyperdrive EFI (model HU937037EX) and Z Diesel (models HU931238EX,HU932699EX and HU938225EX) side discharge zero turn radius (ZTR) models.

3

Extra high lift, notched, flat, Fusion blade, clockwise rotation (flute/sail height1.20"/ 30.48 mm).

1

Please call our friendly sales team if any assistance or further information isrequired.

All blade bars are sold as singles, order the quantity required to make up a set.
