***PURCHASE FROM GA STOCKCODE BLR8539*** FUSION BLADE EXTRA HIGH LIFT - (Sold per blade)

Genuine HUSTLER 66" Cut Side Discharge Extra High Lift Notched Fusion Bar Blade

Genuine Hustler extra high lift notched Fusion bar blade. Fitted as a servicereplacement blade on the models listed below where an extra high lift blade isrequired. Blade Lift refers to the ability of a blade to provide vacuum to liftgrass so that it can be cut uniformly. More blade lift also contributes to removingdebris out of the grass, clearing debris out of the deck and throwing the grassfurther in side discharge mode. In some conditions, more blade lift can result incausing debris to build up under the deck, while in other conditions, the oppositeis true. Blade "Lift" can be measured from the bottom side of the blade to thehighest point of the blade sail. An extra high lift blade (EHN) provides liftrequired for high velocity style decks. Blade lift for this blade measures 1.20"(30.48 mm).Fusion blades feature an exclusive electro-fusion technology that creates anultra-hard layer at the blade’s cutting edge, the blade remains sharp andcontinues to give a clean cut far longer than any blade on the market.

BigDog 602864HUSTLER 602864

0.63"

16.002 mm

66" cut

1676.4 mm

167.6 cm

22.50"

571.5 mm

0.25"

6.35 mm

3"

76.2 mm

Flute/sail height 1.20"

Flute/sail height 30.48 mm

Round

66" (1676.4 mm) cut HUSTLER Super Z (models HU929943EX, HU932657EX and HU935494EX)and Super Z Hyperdrive (model HU937102EX) side discharge zero turn radius (ZTR)models.

3

Extra high lift, notched, flat, Fusion blade, clockwise rotation (flute/sail height1.20"/ 30.48 mm).

1

Please call our friendly sales team if any assistance or further information isrequired.

All blade bars are sold as singles, order the quantity required to make up a set.
