***PURCHASE FROM GA STOCKCODE BLR8287*** BLADE - GATOR MULCHER,

Genuine BigDog & HUSTLER 48" Cut Gator Mulcher Bar Blade

Genuine Hustler and BigDog Gator mulcher bar blade. Fitted as a service replacementblade on the models listed below where a mulching blade is required. The Gatormulcher blade (GAT) has grooves cut into the blade sail to create multiple edgeswhere the material can be recut. It can be used in catching, side discharge andmulching modes and is particularly effective in reducing the volume of grass anddry leaves left after cutting.

BigDog 796631HUSTLER 796631

0.63"

16.002 mm

48" cut

1220 mm cut

122 cm cut

16.50"

420 mm

0.203"

5.156 mm

2 1/2"

63.5 mm

Round

48" (1220 mm) cut BigDog Alpha MP (models BDU932947EX and BDU936526EX), R Series(model BDU931493AU), Stout (models BDU933549EX, BDU933747EX, BDU935502EX andBDU937649EX) side discharge zero turn radius (ZTR) models.

3

48" (1220 mm) cut HUSTLER FasTrak (models HU930107EX, HU933424EX, HU933523EX,HU938704EX and HU940346EX), FasTrak SDX (models HU938779EX and HU940411EX), RaptorFlipup (model HU935288EX), Raptor SD (models HU932566EX and HU936542EX), Raptor XD(model HU940510EX), Raptor XDX (model HU941492EX), SuperDuty (models HU932426EX andHU933481EX), SuperDuty X (model HU933945EX) and X-One (models HU933135EX,HU934133EX and HU934497EX) side discharge zero turn radius (ZTR) models.

3

Gator mulcher flat blade, clockwise rotation. the sharpened slots in the bladesails / flute area cuts and recuts the grass,

1

Please call our friendly sales team if any assistance or further information isrequired.

All blade bars are sold as singles, order the quantity required to make up a set.
