***PURCHASE FROM GA STOCKCODE BLR8250*** BLADE LOW LIFT, 17.86" -L-F-CW

Genuine BigDog & HUSTLER 36" & 52" Cut Side Discharge Low Lift Bar Blade

Genuine Hustler and BigDog low lift bar blade. Fitted as a production line blade on36" cut side discharge HUSTLER Raptor & Raptor SD. Fitted as a service replacementblade on several other models listed below where a low lift blade is required.Blade Lift refers to the ability of a blade to provide vacuum to lift grass so thatit can be cut uniformly. More blade lift also contributes to removing debris out ofthe grass, clearing debris out of the deck and throwing the grass further in sidedischarge mode. In some conditions, more blade lift can result in causing debris tobuild up under the deck, while in other conditions, the opposite is true. Blade"Lift" can be measured from the bottom side of the blade to the highest point ofthe blade sail. A Low Lift Blade (L) is adequate for shallow decks and mostconsumer applications and can be used to reduce blowout or deck packing in someconditions. Blade lift for this blade measures 0.79" (20.066 mm).

BigDog 783753HUSTLER 783753

0.63"

16.002 mm

36" & 52" cut

915 mm & 1320 mm

91.5 cm & 132 cm

17.86"

453.64 mm

0.203"

5.156 mm

2 1/2"

63.5 mm

Flute/sail height 0.79"

Flute/sail height 20.066 mm

Round

36" (915 mm) cut BigDog A Series (model BDU931337EX) side discharge zero turnradius (ZTR) models.

2

36" (915 mm) cut HUSTLER Raptor SD (models HU935262EX and HU938365EX), HUSTLERSuperDuty (model HU932491EX) and HUSTLER SUPER S (model HU939439) side dischargezero turn radius (ZTR) models.

2

52" (1320 mm) cut BigDog Alpha Series (models BDU932913EX and BDU939124EX, BigDog XSeries (model BDU931543EX) and BigDog Diablo (models BDU933366EX and BDU935551EX)side discharge zero turn radius (ZTR) models.

3

52" (1320 mm) cut HUSTLER Raptor (models HU931899EX, HU938282EX and HU939116EX)side discharge zero turn radius (ZTR) models.

3

Low lift, flat blade, clockwise rotation (flute/sail height 0.79"/ 20.066 mm).

1

Please call our friendly sales team if any assistance or further information isrequired.

All blade bars are sold as singles, order the quantity required to make up a set.

BigDog, HUSTLER

Bar Blade, Blade Bar, Low Lift Bar Blade,
