***PURCHASE FROM GA STOCKCODE BLR8250*** BLADE HIGH LIFT,

Genuine BigDog & HUSTLER 36" & 52" Cut Side Discharge High Lift Bar Blade

Genuine Hustler and BigDog high lift bar blade. Fitted as a production line bladeon 36" cut side discharge HUSTLER Super S. Fitted as a service replacement blade onseveral other models listed below where a high lift blade is required. Blade Liftrefers to the ability of a blade to provide vacuum to lift grass so that it can becut uniformly. More blade lift also contributes to removing debris out of thegrass, clearing debris out of the deck and throwing the grass further in sidedischarge mode. In some conditions, more blade lift can result in causing debris tobuild up under the deck, while in other conditions, the opposite is true. Blade"Lift" can be measured from the bottom side of the blade to the highest point ofthe blade sail. The high Lift Blade (H) is the standard blade for many deep decks.A high lift blade provides more vacuum for better finished apperance. Blade liftfor this blade measures 1.09" / 27.68 mm).

BigDog 787721HUSTLER 787721

0.63"

16.002 mm

36" & 52" cut

915 mm & 1320 mm

91.5 cm & 132 cm

17.86"

453.64 mm

0.203"

5.156 mm

2 1/2"

63.5 mm

Flute/sail height 1.09"

Flute/sail height 27.68 mm

Round

36" (915 mm) cut HUSTLER Raptor SD (models HU935262EX and HU938365EX) and HUSTLERSUPER S (model HU939439) side discharge zero turn radius (ZTR) models.

2

52" (1320 mm) cut BigDog Alpha Series (models BDU932913EX and BDU939124EX), BigDogX Series (model BDU931543EX) and BigDog Diablo (models BDU933366EX, BDU935551EX andBDU936344EX) side discharge zero turn radius (ZTR) models.

3

52" (1320 mm) cut HUSTLER Raptor (models HU931899EX, HU938282EX and HU939116EX)side discharge zero turn radius (ZTR) models.

3

High lift, flat blade, clockwise rotation (flute/sail height 1.09"/ 27.68 mm).

1

Please call our friendly sales team if any assistance or further information isrequired.

All blade bars are sold as singles, order the quantity required to make up a set.
