***PURCHASE FROM GA STOCKCODE BLR8166*** BLADE - WAVY MULCHER,

Genuine BigDog & HUSTLER 54" Cut Wavy Mulcher Bar Blade

Genuine Hustler and BigDog wavy mulcher bar blade. Fitted as a service replacementblade on the models listed below where a mulching blade is required. The wavymulcher blade (MUL) has both a positive lift on the outside of the blade and anegative lift toward the inside of the blade. This serves to agitate the grassinside the deck to bring it into more contact with the cutting surfaces and therebyreduce clipping size. While this is primarily for decks with mulching kitsinstalled, using a wavy mulch blade in side discharge mode also reduces clippingsize.

BigDog 797704HUSTLER 797704

0.63"

16.002 mm

54" cut

1372 mm cut

137.2 cm cut

18.50"

469.9 mm

0.203"

5.156 mm

2 1/2"

63.5 mm

Round

54" (1372 mm) cut BigDog Alpha MP (models BDU932939EX, BDU936518EX andBDU937573EX), C Series (model BDU933598EX), R Series (model BDU931519EX) and Stout(models BDU933556EX, BDU933754EX, BDU935510EX and BDU937656EX) side discharge zeroturn radius (ZTR) models.

3

54" (1372 mm) cut HUSTLER FasTrak (models HU930115EX, HU933432EX, HU933531EX,HU938712EX and HU940353EX), FasTrak SDX (models HU933952EX, HU938787EX andHU940429EX), Raptor SD (models HU932558EX, HU936534EX and HU938381EX), Raptor X(model HU940502EX), Raptor XD (model HU939751EX), Raptor XDX (model HU941500EX),Sport (model HU933473EX), SuperDuty (models HU932434EX and HU933499EX), Super Z(models HU938100EX, HU938878EX and HU941138EX), X-One (models HU932780EX,HU934158EX and HU934810EX) and Z Diesel SD (models HU931196EX and HU932665EX) sidedischarge zero turn radius (ZTR) models.

3

Wavy mulcher blade, clockwise rotation. Cuts and recuts the grass reducing clippingsize.

1

Please call our friendly sales team if any assistance or further information isrequired.

All blade bars are sold as singles, order the quantity required to make up a set.

BigDog, HUSTLER

Bar Blade, Blade Bar, Mulcher Blade, Mulching Blade, Wavy Mulcher Blade,
