Genuine Hustler and BigDog Gator mulcher bar blade. Fitted as a service replacementblade on the models listed below where a mulching blade is required. The Gatormulcher blade (GAT) has grooves cut into the blade sail to create multiple edgeswhere the material can be recut. It can be used in catching, side discharge andmulching modes and is particularly effective in reducing the volume of grass anddry leaves left after cutting.
BigDog 794230HUSTLER 794230
0.63"
16.002 mm
42", 60" & 104" cut
1067 mm, 1524 mm & 2641.6 mm cut
106.7 cm, 152.4 cm & 264.1 cm cut
20.50"
520.7 mm
0.203"
5.156 mm
2 1/2"
63.5 mm
Round
42" (1067 mm) cut BigDog A Series (model BDU931345EX), Alpha Series (modelsBDU932897EX, BDU934489EX and BDU939140EX) and Alpha MP (model BDU936393EX) and CSeries (models BDU931428EX, BDU931436EX and BDU933572EX) side discharge zero turnradius (ZTR) models.
2
42" (1067 mm) cut HUSTLER Raptor (models HU933465EX, HU934679EX, HU938332EX andHU939108EX), Raptor SD (models HU935270EX, HU936559EX and HU938407EX), Raptor X(model HU940494EX), Raptor XD (model HU939819EX), Sport (model HU932293EX) andSuperDuty (model HU932517EX) side discharge zero turn radius (ZTR) models.
2
60" (1524 mm) cut BigDog Diablo MP (model BDU937292EX), R Series (modelBDU931535AU) and Stout (models BDU933168EX, BDU933762EX, BDU935528EX andBDU937664EX) side discharge zero turn radius (ZTR) models.
3
60" (1524 mm) cut HUSTLER ATZ (model HU931915EX), FasTrak (models HU930784EX,HU933440EX, HU938720EX, HU940361EX and HU940437EX), FasTrak SDX (model HU938795EX),Raptor XDX (model HU941518EX), Super Z SD (models HU932160EX, HU938118EX,HU938886EX and HU941146EX), Super Z HD SD (models HU935254EX, HU940551EX andHU941310EX), Super Z EFI SD (model HU934927EX), Super Z Hyperdrive SD (modelHU937060EX), Super Z Hyperdrive EFI SD (model HU937003EX), SuperDuty (modelsHU932442EX and HU933507EX), SuperDuty X (model HU933960EX), X-One (modelsHU932723EX, HU934174EX and HU934836EX) and Z Diesel SD (models HU931204EX,HU932673EX and HU938183EX) side discharge zero turn radius (ZTR) models.
3
60" (1524 mm) cut HUSTLER Z Diezel (models HU931212EX, HU932681EX and HU938191EX),Super Z (models HU932178EX, HU935320EX, HU938126EX and HU941195EX ), Super Z HD(model HU941336EX), Super Z Hyperdrive (model HU937078EX) rear discharge zero turnradius (ZTR) models.
For 60" cut rear discharge decks use HP794230 x 2 qty and HP601928 x 1 qty.
104" (2641.6 mm) cut HUSTLER Super 104 (models HU931733EX, HU938910EX, HU939603EXand HU940544EX *on the centre rear discharge deck only) zero turn radius (ZTR)models.
*For the centre rear discharge decks use HP794230 x 2 qty and HP601928 x 1 qty (usewith - for left hand side deck use HP601929 x 1 qty, for right hand side deck useHP794867 x 1 qty).
Gator mulcher flat blade, clockwise rotation. the sharpened slots in the bladesails / flute area cuts and recuts the grass,
1
Please call our friendly sales team if any assistance or further information isrequired.
All blade bars are sold as singles, order the quantity required to make up a set.
