***PURCHASE FROM GA STOCKCODE BLR7701*** FUSION BLADE HIGH LIFT,
Genuine BigDog & HUSTLER 54" Cut Side Discharge High Lift Fusion Bar Blade
Genuine Hustler and BigDog high lift Fusion bar blade. Fitted as a production lineblade on the Hustler Super Z. Fitted as a service replacement blade on the othermodels listed below where a high lift blade is required. Blade Lift refers to theability of a blade to provide vacuum to lift grass so that it can be cut uniformly.More blade lift also contributes to removing debris out of the grass, clearingdebris out of the deck and throwing the grass further in side discharge mode. Insome conditions, more blade lift can result in causing debris to build up under thedeck, while in other conditions, the opposite is true. Blade "Lift" can be measuredfrom the bottom side of the blade to the highest point of the blade sail. The highLift Blade (H) is the standard blade for many deep decks. A high lift bladeprovides more vacuum for better finished apperance. Blade lift for this blademeasures 1.09" / 27.68 mm). Fusion blades feature an exclusive electro-fusiontechnology that creates an ultra-hard layer at the blade’s cutting edge, theblade remains sharp and continues to give a clean cut far longer than any blade onthe market.
BigDog 797696HUSTLER 797696
0.63"
16.002 mm
54" cut
1372 mm
137.2 cm
18.50"
469.9 mm
0.203"
5.156 mm
2 1/2"
63.5 mm
Flute/sail height 1.09"
Flute/sail height 27.68 mm
Round
54" (1372 mm) cut BigDog Alpha MP (models BDU932939EX, BDU936518EX andBDU937573EX), C Series (model BDU933598EX), R Series (model BDU931519EX) and Stout(models BDU933556EX, BDU933754EX and BDU937656EX) side discharge zero turn radius(ZTR) models.
3
54" (1372 mm) cut HUSTLER FasTrak (models HU930115EX, HU933432EX, HU933531EX,HU938712EX and HU940353EX), FasTrak SDX (models HU933952EX, HU938787EX andHU940429EX), Raptor SD (models HU932558EX, HU936534EX and HU938381EX), Raptor X(model HU940502EX), Raptor XD (model HU939751EX), Raptor XDX (model HU941500EX),Sport (model HU933473EX), SuperDuty (models HU930149EX, HU932434EX and HU933499EX),Super Z (models HU938100EX, HU938878EX and HU941138EX), X-One (models HU932780EX,HU934158EX, HU934810EX, HU936740EX and HU941112EX) and Z Diesel SD (modelsHU931196EX and HU932665EX) side discharge zero turn radius (ZTR) models.
3
High lift, flat Fusion blade, clockwise rotation (flute/sail height 1.09"/ 27.68mm). Fusion blades feature an exclusive electro-fusion technology that creates anultra-hard layer at the blade’s cutting edge, the blade remains sharp andcontinues to give a clean cut far longer than any blade on the market.
1
Please call our friendly sales team if any assistance or further information isrequired.
All blade bars are sold as singles, order the quantity required to make up a set.
