***PURCHASE FROM GA STOCKCODE BLR7701*** BLADE LOW LIFT,

Genuine BigDog & HUSTLER 54" Cut, Side Discharge Low Lift Bar Blade

Genuine Hustler and BigDog low lift bar blade. Fitted as a production line blade on54" cut side discharge HUSTLER Raptor SD models. Fitted as a service replacementblade on many other models listed below where a low lift blade is required. BladeLift refers to the ability of a blade to provide vacuum to lift grass so that itcan be cut uniformly. More blade lift also contributes to removing debris out ofthe grass, clearing debris out of the deck and throwing the grass further in sidedischarge mode. In some conditions, more blade lift can result in causing debris tobuild up under the deck, while in other conditions, the opposite is true. Blade"Lift" can be measured from the bottom side of the blade to the highest point ofthe blade sail. A Low Lift Blade (L) is adequate for shallow decks and mostconsumer applications and can be used to reduce blowout or deck packing in someconditions. Blade lift for this blade measures 0.79" (20.066 mm).

BigDog 601124HUSTLER 601124

0.63"

16.002 mm

54" cut

1372 mm cut

137.2 cm cut

18.50"

469.9 mm

0.203"

5.156 mm

2 1/2"

63.5 mm

Flute/sail height 0.79"

Flute/sail height 20.066 mm

Round

54" (1372 mm) cut BigDog Alpha MP (models BDU932939EX and BDU937573EX), C Series(model BDU933598EX), R Series (model BDU931519EX) and Stout (models BDU933556EX,BDU933754EX, BDU935510EX and BDU937656EX) side discharge zero turn radius (ZTR)models.

3

54" (1372 mm) cut HUSTLER FasTrak (models HU928267EX, HU928275EX, HU928291EX,HU928502EX, HU930115EX, HU933432EX, HU933531EX, HU938712EX and HU940353EX), FasTrakSDX (models HU933952EX, HU938787EX and HU940429EX), Raptor SD (models HU932558EX,HU936534EX and HU938381EX), Sport (model HU933473EX), SuperDuty (models HU932434EXand HU933499EX) and Super Z (models HU938100EX, HU938878EX and HU941138EX) sidedischarge zero turn radius (ZTR) models.

3

Low lift, flat blade, clockwise rotation (flute/sail height 0.79"/ 20.066 mm).

1

Please call our friendly sales team if any assistance or further information isrequired.

All blade bars are sold as singles, order the quantity required to make up a set.

BigDog, HUSTLER
