***PURCHASE FROM GA STOCKCODE BLR7668*** FUSION BLADE LOW LIFT, (Sold per blade)

Genuine BigDog & HUSTLER 48" Cut, Side Discharge Low Lift Fusion Bar Blade

Genuine Hustler and BigDog low lift Fusion bar blade. Fitted as a servicereplacement blade on the models listed below where a low lift blade is required.Blade Lift refers to the ability of a blade to provide vacuum to lift grass so thatit can be cut uniformly. More blade lift also contributes to removing debris out ofthe grass, clearing debris out of the deck and throwing the grass further in sidedischarge mode. In some conditions, more blade lift can result in causing debris tobuild up under the deck, while in other conditions, the opposite is true. Blade"Lift" can be measured from the bottom side of the blade to the highest point ofthe blade sail. A Low Lift Blade (L) is adequate for shallow decks and mostconsumer applications and can be used to reduce blowout or deck packing in someconditions. Blade lift for this blade measures 0.79" (20.066 mm). Fusion bladesfeature an exclusive electro-fusion technology that creates an ultra-hard layer atthe blade’s cutting edge, the blade remains sharp and continues to give a cleancut far longer than any blade on the market.

BigDog 601014HUSTLER 601014

0.63"

16.002 mm

48" cut

1220 mm cut

122 cm cut

16.50"

419.1 mm

0.203"

5.156 mm

2 1/2"

63.5 mm

Flute/sail height 0.79"

Flute/sail height 20.066 mm

Round

48" (1220 mm) cut BigDog Alpha MP (models BDU932947EX and BDU936526EX), Stout(model BDU937649EX) side discharge zero turn radius (ZTR) models.

3

48" (1220 mm) cut HUSTLER FasTrak (models HU938704EX and HU940346EX), FasTrak SDX(models HU938779EX and HU940411EX), Raptor Flipup (model HU935288EX), Raptor SD(models HU932566EX and HU936542EX), Raptor XD (model HU940510EX), Raptor XDX (modelHU941492EX), X-One (models HU933135EX, HU934133EX and HU934497EX) side dischargezero turn radius (ZTR) models.

3

Low lift, flat fusion blade, clockwise rotation (flute/sail height 0.79"/ 20.066mm). Fusion blades feature an exclusive electro-fusion technology that creates anultra-hard layer at the blade’s cutting edge, the blade remains sharp andcontinues to give a clean cut far longer than any blade on the market.

1

Please call our friendly sales team if any assistance or further information isrequired.

All blade bars are sold as singles, order the quantity required to make up a set.

BigDog, HUSTLER

Bar Blade, Blade Bar, Low Lift Bar Blade,
