***PURCHASE FROM GA STOCKCODE BLR6918*** FUSION BLADE LOW LIFT,
Genuine BigDog & HUSTLER 36", 42", 60" & 104" Cut, Side and Rear Discharge Low LiftFusion Bar Blade
Genuine Hustler and BigDog low lift Fusion bar blade. Fitted as a production lineblade on 60" cut rear-discharge HUSTLER Super Z, HD and on the Super 104 (on thecentre deck). Fitted as a service replacement blade on many other models listedbelow where a low lift blade is required. Blade Lift refers to the ability of ablade to provide vacuum to lift grass so that it can be cut uniformly. More bladelift also contributes to removing debris out of the grass, clearing debris out ofthe deck and throwing the grass further in side discharge mode. In some conditions,more blade lift can result in causing debris to build up under the deck, while inother conditions, the opposite is true. Blade "Lift" can be measured from thebottom side of the blade to the highest point of the blade sail. A Low Lift Blade(L) is adequate for shallow decks and most consumer applications and can be used toreduce blowout or deck packing in some conditions. Blade lift for this blademeasures 0.79" (20.066 mm). Fusion blades feature an exclusive electro-fusiontechnology that creates an ultra-hard layer at the blade’s cutting edge, theblade remains sharp and continues to give a clean cut far longer than any blade onthe market.
BigDog 600901HUSTLER 600901
0.63"
16.002 mm
36", 42", 60" & 104" cut
915 mm, 1067 mm, 1524 mm & 2641.5 mm
91.5 cm, 106.7 cm, 152.4 cm & 264.15 cm
20.50"
520.7 mm
0.203"
5.156 mm
2 1/2"
63.5 mm
Flute/sail height 0.79"
Flute/sail height 20.066 mm
Round
36" (915 mm) cut HUSTLER SuperDuty (model *HU931253EX) side discharge zero turnradius (ZTR) models.
*Use HP600901 x 1 qty and HP600900 x 1 qty for 36" cut.
42" (1067 mm) cut BigDog C Series (models BDU931428EX, BDU931436EX and BDU933572EX)side discharge zero turn radius (ZTR) models.
2
42" (1067 mm) cut HUSTLER Raptor (model HU938332EX), Raptor X (model HU940494EX),Raptor XD (model HU939819EX) and Sport (model HU932293EX) side discharge zero turnradius (ZTR) models.
2
60" (1524 mm) cut BigDog Stout (models BDU931436EX, BDU933762EX and BDU937664EX)side discharge zero turn radius (ZTR) models.
3
60" (1524 mm) cut HUSTLER FasTrak (models HU930784EX, HU938720EX, HU933440EX,HU940361EX and HU940437EX), FasTrak SDX (938795EX), Raptor XDX (model HU941518EX),SuperDuty (models HU932442EX and HU933507EX) and SuperDuty X (model HU933960EX)side discharge zero turn radius (ZTR) models.
3
60" (1524 mm) cut HUSTLER Z Diezel (models HU931212EX, HU938191EX and HU938191EX),Super Z (models HU930024EX, HU932178EX, HU935320EX, HU938126EX and HU941195EX),Super Z HD (model HU941336EX), Super Z Hyperdrive (model HU937078EX) rear dischargezero turn radius (ZTR) models.
For 60" cut rear discharge decks use HP600901 x 2 qty and HP795633 x 1 qty.
104" (2641.6 mm) cut HUSTLER Super 104 (models HU931733EX, HU938910EX, HU939603EXand HU940544EX) *on the centre rear discharge deck only) zero turn radius (ZTR)models.
*For the centre rear discharge decks use HP600901 x 2 qty and HP795633 x 1 qty (Formodels HU939603EX and HU940544EX) use with - for left hand side deck use HP606392 x1 qty, for right hand side deck use HP606393 x 1 qty and for models HU931733EX andHU938910EX use with - for left hand side deck use HP796508 x 1 qty, for right handside deck use HP796839 x 1 qty).
Low lift, flat fusion blade, clockwise rotation (flute/sail height 0.79"/ 20.066mm). Fusion blades feature an exclusive electro-fusion technology that creates anultra-hard layer at the blade’s cutting edge, the blade remains sharp andcontinues to give a clean cut far longer than any blade on the market.
1
Please call our friendly sales team if any assistance or further information isrequired.
Please Note: All blade bars are sold as singles, order the quantity required tomake up a set.
