***PURCHASE FROM GA STOCKCODE BLR6918*** FUSION BLADE HIGH LIFT,
Genuine BigDog & HUSTLER 42" & 60" Cut Side Discharge High Lift Fusion Bar Blade
Genuine Hustler and BigDog high lift Fusion bar blade. Fitted as a servicereplacement blade on the models listed below where a high lift blade is required.Blade Lift refers to the ability of a blade to provide vacuum to lift grass so thatit can be cut uniformly. More blade lift also contributes to removing debris out ofthe grass, clearing debris out of the deck and throwing the grass further in sidedischarge mode. In some conditions, more blade lift can result in causing debris tobuild up under the deck, while in other conditions, the opposite is true. Blade"Lift" can be measured from the bottom side of the blade to the highest point ofthe blade sail. The high Lift Blade (H) is the standard blade for many deep decks.A high lift blade provides more vacuum for better finished apperance. Blade liftfor this blade measures 1.09" / 27.68 mm). Fusion blades feature an exclusiveelectro-fusion technology that creates an ultra-hard layer at the blade’s cuttingedge, the blade remains sharp and continues to give a clean cut far longer than anyblade on the market.
BigDog 794685HUSTLER 794685
0.63"
16.002 mm
42" & 60" cut
1067 mm & 1524 mm cut
106.7 cm & 152.4 cm cut
20.50"
520.7 mm
0.203"
5.156 mm
2 1/2"
63.5 mm
Flute/sail height 1.09"
Flute/sail height 27.68 mm
Round
42" (1067 mm) cut BigDog Alpha Series (models BDU932897EX, BDU934489EX andBDU939140EX) and Alpha MP (model BDU936393EX) side discharge zero turn radius (ZTR)models.
2
42" (1067 mm) cut HUSTLER Raptor (models HU933465EX, HU934679EX, HU938332EX andHU939108EX), Raptor SD (models HU935270EX, HU936559EX and HU938407EX), Raptor X(model HU940494EX), Raptor XD (model HU939819EX), Sport (model HU932293EX) andSuperDuty (model HU932517EX) side discharge zero turn radius (ZTR) models.
2
60" (1524 mm) cut BigDog Diablo (model BDU936351EX), Diablo MP (model BDU937292EX),R Series (model BDU931535AU) and Stout (models BDU933168EX, BDU933762EX andBDU937664EX) side discharge zero turn radius (ZTR) models.
3
60" (1524 mm) cut HUSTLER ATZ (model HU931915EX), FasTrak (models HU930784EX,HU933440EX, HU938720EX, HU940361EX and HU940437EX), FasTrak SDX (model HU938795EX),Raptor XDX (model 941518EX), Super Z SD (models HU932160EX, HU938118EX, HU938886EXand HU941146EX), Super Z HD SD (models HU935254EX, HU940551EX and HU941310EX),Super Z EFI SD (model HU934927EX), Super Z Hyperdrive SD (model HU937060EX), SuperZ Hyperdrive EFI SD (model HU937003EX), SuperDuty (models HU930164EX, HU932442EXand HU933507EX), SuperDuty X (model HU933960EX), X-One (models HU932723EX,HU934174EX, HU934836EX, HU936799EX and HU941120EX) and Z Diesel SD (modelsHU931204EX, HU932673EX and HU938183EX) side discharge zero turn radius (ZTR) models.
3
High lift, flat Fusion blade, clockwise rotation (flute/sail height 1.09"/ 27.68mm). Fusion blades feature an exclusive electro-fusion technology that creates anultra-hard layer at the blade’s cutting edge, the blade remains sharp andcontinues to give a clean cut far longer than any blade on the market.
1
Please call our friendly sales team if any assistance or further information isrequired.
All blade bars are sold as singles, order the quantity required to make up a set.
