Kawasaki FR691V-CS18-S, 23 hp (17.2 kW) Vertical Shaft Engine With A 1 1/8" x 100mm Crankshaft
Kawasaki FR Series engines are engineered to blend muscle, economy, and efficiencyinto a residential-use powerhouse. Torque and power are ideal for lawn andlandscape grasses. Operation is smooth and quiet, perfect for neighbourhood use.Compact design means nimble operation, and Kawasaki durability helps ensure longservice life. When it comes to getting things done, this is the engine that bringsprofessional quality home.
Overhead V-valve 90° V-twin.Single-stage air filter .Pressurized lubrication system.Electronic spark ignition.Automatic compression release.Internally vented carburetor with fuel shut-off solenoid.Cast-iron cylinder liners.Rotating metal grass chopper screen.
Air cooled, 90 degree V-twin, normally aspirated petrol engine.
726 cc
23 hp (17.2 kW) at 3,600 RPM (Please Note: Horsepower rating as tested to SAE J1995Standards.)
Two, 90° V-twin.
Cast-iron cylinder liners.
3.1 x 3.0 in. (78 x 76mm).
726 cc (44.3 cu. in.).
8.2:1
Air cooled. Fly-wheel fan.
Maximum Power 23 hp (17.2 kW) at 3,600 RPM (Please Note: Horsepower rating as tested to SAE J1995 Standards.)
Maximum Torque 39.3 ft-lbs (53.2 N·m) at 2,200 RPM.
Automatic compression release.
Electronic spark ignition.
1 1/8" x 100 mm (28 X 100mm)
Cartridge air filter.
12-volt.
12-volt.
No.
Unleaded fuel - maximum of 10% ethanol in fuel.
Yes, replaceable, automotive-type.
Mechanical.
Yes, spin-on engine oil filter.
Oil Capacity w/filter 2.1 U.S. qt ( 2.0 litres).
88.2 lbs.
40 kg.
Kawasaki Commercial Engine Warranty Policy for Australia GA Power Equipment Spareswarrants to the original purchaser of each new Kawasaki four-cycle engine that suchproduct shall be free, under normal use and maintenance, from any defect inmaterials and/or workmanship for a period of thirty-six (36) months for unitspurchased on or after 1st September 2017. Any unit purchased prior to 1st September2017 will be covered for a period of twenty-four (24) months after the date ofpurchase, subject to the following conditions, exclusions, obligations andlimitations for models FR, FS, FX, FD, FJ.COVERAGEAny material and/or workmanship in four–cycle engines found to be defective byKawasaki within the thirty-six (36) months for units purchased on or after 1stSeptember 2017. Any unit purchased prior to 1st September 2017 will be covered fora period of twenty-four (24) month warranty term for models FR, FS, FX, FD, FJ.Shall be remedied without charge for parts or labour at any authorised KawasakiEngine Dealer located in Australia. A Kawasaki part or accessory sold and installedby an authorised Kawasaki Engine Dealer, which is found defective in materialand/or workmanship, within the three (3) month warranty term, shall be repaired orreplaced (at the option of Kawasaki) without charge for the part or accessory, atany authorised Kawasaki Engine Dealer located in Australia.CUSTOMER RESPONSIBILITIESThe following obligations must be fulfilled by the owner to maintain the validityof Kawasaki Warranty for Australia. Owner must deliver the four-cycle engine to anAuthorised Kawasaki Engine Dealer for inspection, maintenance services andadjustments as per the Australian periodic maintenance chart. The inspection,maintenance services and adjustments are to be performed at the owner’s expense.Owner must present proof of initial retail purchase date to an Authorised KawasakiEngine dealer at the time warranty repairs are performed on the four-cycle engine.LIMITATIONSThis warranty shall not apply to or include any of the following: Repair orreplacement required as a result of accident, misuse or neglect, lack of reasonableand proper maintenance, repairs improperly performed or replacements improperlyinstalled, useof non-genuine Kawasaki replacement parts or accessories, alterations ormodifications not recommended by Kawasaki, wear and deterioration occasioned by theby the use of the four-cycle engine, the use of stale or incorrect fuel. Routinemaintenance services, adjustments, cleaning and/or expendables such as spark plugs,lubricants, oil filters, air filters and fuel filters.LIMITED LIABILITYThe liability of Kawasaki under the thirty-six (36) months for units purchased onor after 1st September 2017. Any unit purchased prior to 1st September 2017 will becovered for a period of twenty-four (24) months warranty for models FR, FS, FX, FD,FJ is limited solely to the remedying of defects in materials and/or workmanship byan Authorised Kawasaki Engine Dealer at its place of business during customarybusiness hours. This warranty does not cover inconvenience or loss of use of thefour-cycle engine or transportation of the four-cycle engine to and from theKawasaki Dealer.AUSTRALIAN CONSUMER LAW (reg.90)Our goods come with guarantees that cannot be excluded under the AustralianConsumer Law. You are entitled to a replacement or refund for a major failure andfor compensation for any other reasonably foreseeable loss of damage. You are alsoentitled to have the goods repaired or replaced if the goods fail to be ofacceptable quality and the failure does not amount to a major failure. The textabove applies not withstanding anything else expressed or implied to the contraryin this Warranty document.
1
Specifications subject to change without notice.
*PLEASE NOTE: Horsepower rating as tested to SAE J1995 Standards.*
