FUSION BLADE, F23.86-L-F-CW 104" CUT REAR DISCHARGE, RIGHT WING CLOCKWISE

Genuine HUSTLER 104" Cut, Rear Discharge Low Lift Fusion Bar Blade

Genuine Hustler low lift Fusion bar blade. Fitted as a production line blade onselected Super 104 models (on the right-hand side wing deck). Blade Lift refers tothe ability of a blade to provide vacuum to lift grass so that it can be cutuniformly. More blade lift also contributes to removing debris out of the grass,clearing debris out of the deck and throwing the grass further in side dischargemode. In some conditions, more blade lift can result in causing debris to build upunder the deck, while in other conditions, the opposite is true. Blade "Lift" canbe measured from the bottom side of the blade to the highest point of the bladesail. A Low Lift Blade (L) is adequate for shallow decks and most consumerapplications and can be used to reduce blowout or deck packing in some conditions.Blade lift for this blade measures 0.79" (20.066 mm). Fusion blades feature anexclusive electro-fusion technology that creates an ultra-hard layer at theblade’s cutting edge, the blade remains sharp and continues to give a clean cutfar longer than any blade on the market.

HUSTLER 606393

0.63"

16.002 mm

104" cut

2642 mm

264.2 cm

23.86"

606 mm

0.25"

6.35 mm

3"

76.2 mm

Flute/sail height 0.79"

Flute/sail height 20.066 mm

Round

104" (2642 mm) cut selected HUSTLER Super 104 (models HU939603EX and HU940544EX *onthe right-hand side wing deck only) zero turn radius (ZTR) models.

For the centre rear discharge deck use HP600901 x 2 qty and HP795633 x 1 qty (Formodel HU939603EX use with -for left hand side deck use HP606392 x 1 qty, *for righthand side deck use HP606393 x 1 qty).

Low lift, flat Fusion blade, clockwise rotation (flute/sail height 0.79"/ 20.066mm). Fusion blades feature an exclusive electro-fusion technology that creates anultra-hard layer at the blade’s cutting edge, the blade remains sharp andcontinues to give a clean cut far longer than any blade on the market.

1

Please call our friendly sales team if any assistance or further information isrequired.

All blade bars are sold as singles, order the quantity required to make up a set.
