BLADE - WAVY MULCHER, 22.50"-MUL-F-CW 46" & 66" CUT SIDE DISCHARGE (Sold per blade)

Genuine BigDog 46" Cut & HUSTLER 66" Cut Wavy Mulcher Bar Blade

Genuine Hustler and BigDog wavy mulcher bar blade. Fitted as a service replacementblade on the models listed below where a mulching blade is required. The wavymulcher blade (MUL) has both a positive lift on the outside of the blade and anegative lift toward the inside of the blade. This serves to agitate the grassinside the deck to bring it into more contact with the cutting surfaces and therebyreduce clipping size. While this is primarily for decks with mulching kitsinstalled, using a wavy mulch blade in side discharge mode also reduces clippingsize.

BigDog 798504HUSTLER 798504

0.63"

16.002 mm

46" & 66" cut

1168.4 mm cut & 1676.4 mm cut

116.8 & 167.6 cm cut

22.50"

571.5 mm

0.203"

5.156 mm

3"

76.2 mm

Round

46" (1168 mm) cut BigDog C Series (models BDU931451EX and BDU933580EX) sidedischarge zero turn radius (ZTR) models.

2

66" (1676.4 mm) cut HUSTLER Super Z (models HU932657EX and HU935494EX) and Super ZHyperdrive (model HU937102EX) side discharge zero turn radius (ZTR) models.

3

Wavy mulcher blade, clockwise rotation. Cuts and recuts the grass reducing clippingsize.

1

Please call our friendly sales team if any assistance or further information isrequired.

All blade bars are sold as singles, order the quantity required to make up a set.

BigDog, HUSTLER

Bar Blade, Blade Bar, Mulcher Blade, Mulching Blade, Wavy Mulcher Blade,
