Genuine Hustler and BigDog wavy mulcher bar blade. Fitted as a service replacementblade on the models listed below where a mulching blade is required. The wavymulcher blade (MUL) has both a positive lift on the outside of the blade and anegative lift toward the inside of the blade. This serves to agitate the grassinside the deck to bring it into more contact with the cutting surfaces and therebyreduce clipping size. While this is primarily for decks with mulching kitsinstalled, using a wavy mulch blade in side discharge mode also reduces clippingsize.
BigDog 794214HUSTLER 794214
0.63"
16.002 mm
42", 60" & 104" cut
1067 mm, 1524 mm & 2641.6 mm cut
106.7 cm, 152.4 cm & 264.1 cm cut
20.50"
520.7 mm
0.203"
5.156 mm
2 1/2"
63.5 mm
Round
42" (1067 mm) cut BigDog A Series (model BDU931345EX), Alpha Series (modelsBDU932897EX and BDU934489EX) and Alpha MP (model BDU936393EX) and C Series (modelsBDU931428EX, BDU931436EX and BDU933572EX) side discharge zero turn radius (ZTR)models.
2
42" (1067 mm) cut HUSTLER Raptor (models HU933465EX, HU934679EX and HU938332EX),Raptor SD (models HU935270EX, HU936559EX and HU938407EX), Raptor X (model940494EX), Raptor XD (model 939819EX), Sport (model HU932293EX) and SuperDuty(model HU932517EX) side discharge zero turn radius (ZTR) models.
2
60" (1524 mm) cut BigDog Diablo (model BDU936351EX), Diablo MP (modelBDU937292EX), R Series (model BDU931535AU) and Stout (models BDU933168EX,BDU933762EX, BDU935528EX and BDU937664EX) side discharge zero turn radius (ZTR)models.
3
60" (1524 mm) cut HUSTLER ATZ (model HU931915EX), FasTrak (models HU930784EX,HU933440EX, HU938720EX, HU940361EX and HU940437EX), FasTrak SDX (model HU938795EX),Raptor XDX (model HU941518EX), Super Z SD (models HU932160EX, HU938118EX,HU938886EX and HU941146EX), Super Z HD SD (model HU935254EX), Super Z EFI SD (modelHU934927EX), Super Z HD (models HU940551EX and HU941310EX), Super Z Hyperdrive SD(model HU937060EX), Super Z Hyperdrive EFI SD (model HU937003EX), SuperDuty (modelsHU932442EX and HU933507EX), SuperDuty X (model HU933960EX), X-One (modelsHU932723EX, HU934174EX and HU934836EX) and Z Diesel SD (models HU931204EX,HU932673EX and HU938183EX and HU938183EX) side discharge zero turn radius (ZTR)models.
3
60" (1524 mm) cut HUSTLER Super Z Hyperdrive (model HU937078EX) rear discharge zeroturn radius (ZTR) models.
For 60" cut rear discharge decks use HP794214 x 2 qty and HP604163 x 1 qty.
104" (2641.6 mm) cut HUSTLER Super 104 (models HU931733EX, HU938910EX, HU939603EXand HU940544EX *on the centre rear discharge deck only) zero turn radius (ZTR)models.
*For the centre rear discharge decks use HP794214 x 2 qty and HP604163 x 1 qty (usewith - for left hand side deck use HP604164 x 1 qty, for right hand side deck useHP793398 x 1 qty).
Wavy mulcher blade, clockwise rotation. Cuts and recuts the grass reducing clippingsize.
1
Please call our friendly sales team if any assistance or further information isrequired.
All blade bars are sold as singles, order the quantity required to make up a set.
BigDog, HUSTLER
Bar Blade, Blade Bar, Mulcher Blade, Mulching Blade, Wavy Mulcher Blade,
