BLADE - WAVY MULCHER, 16.50"-MUL-F-CW 48" CUT SIDE DISCHARGE (Sold per blade)

Genuine BigDog & HUSTLER 48" Cut Wavy Mulcher Bar Blade

Genuine Hustler and BigDog wavy mulcher bar blade. Fitted as a service replacementblade on the models listed below where a mulching blade is required. The wavymulcher blade (MUL) has both a positive lift on the outside of the blade and anegative lift toward the inside of the blade. This serves to agitate the grassinside the deck to bring it into more contact with the cutting surfaces and therebyreduce clipping size. While this is primarily for decks with mulching kitsinstalled, using a wavy mulch blade in side discharge mode also reduces clippingsize.

BigDog 796623HUSTLER 796623

0.63"

16.002 mm

48" cut

1220 mm cut

122 cm cut

16.50"

420 mm

0.203"

5.156 mm

2 1/2"

63.5 mm

Round

48" (1220 mm) cut BigDog Alpha MP (models BDU932947EX and BDU936526EX), R Series(model BDU931493AU), Stout (models BDU933549EX, BDU933747EX, BDU935502EX andBDU937649EX) side discharge zero turn radius (ZTR) models.

3

48" (1220 mm) cut HUSTLER FasTrak (models HU930107EX, HU933424EX, HU933523EX,HU938704EX and HU940346EX), FasTrak SDX (models HU938779EX and HU940411EX), RaptorFlipup (model HU935288EX), Raptor SD (models HU932566EX and HU936542EX), Raptor XD(model HU940510EX), Raptor XDX (model HU941492EX), SuperDuty (models HU932426EX andHU933481EX), SuperDuty X (model HU933945EX) and X-One (models HU933135EX,HU934133EX and HU934497EX) side discharge zero turn radius (ZTR) models.

3

Wavy mulcher blade, clockwise rotation. Cuts and recuts the grass reducing clippingsize.

1

Please call our friendly sales team if any assistance or further information isrequired.

All blade bars are sold as singles, order the quantity required to make up a set.

BigDog, HUSTLER

Bar Blade, Blade Bar, Mulcher Blade, Mulching Blade, Wavy Mulcher Blade,
