BLADE HIGH LIFT, 20.50" -H-F-CW 60" CUT SIDE DISCHARGE

Genuine BigDog & HUSTLER 60" Cut Side Discharge High Lift Bar Blade

Genuine Hustler and BigDog high lift bar blade. Fitted as a production line bladeon 60" cut side discharge HUSTLER FasTrak and Fastrak SDX. Fitted as a servicereplacement blade on several other models listed below where a high lift blade isrequired. Blade Lift refers to the ability of a blade to provide vacuum to liftgrass so that it can be cut uniformly. More blade lift also contributes to removingdebris out of the grass, clearing debris out of the deck and throwing the grassfurther in side discharge mode. In some conditions, more blade lift can result incausing debris to build up under the deck, while in other conditions, the oppositeis true. Blade "Lift" can be measured from the bottom side of the blade to thehighest point of the blade sail. The high Lift Blade (H) is the standard blade formany deep decks. A high lift blade provides more vacuum for better finishedapperance. Blade lift for this blade measures 1.09" / 27.68 mm).

BigDog 606253HUSTLER 606253

0.63"

16.002 mm

60" cut

1524 mm

152.4 cm

20.50"

520.7 mm

0.203"

5.156 mm

2 1/2"

63.5 mm

Flute/sail height 1.09"

Flute/sail height 27.68 mm

Round

60" (1524 mm) cut BigDog Stout (models BDU935528EX and BDU937664EX) side dischargezero turn radius (ZTR) models.

3

60" (1524 mm) cut HUSTLER FasTrak (models HU938720EX, HU940361EX and HU940437EX),FasTrak SDX (model HU938795EX) and Raptor XDX (model 941518EX) side discharge zeroturn radius (ZTR) models.

3

High lift, flat blade, clockwise rotation (flute/sail height 1.09"/ 27.68 mm).

1

Please call our friendly sales team if any assistance or further information isrequired.

All blade bars are sold as singles, order the quantity required to make up a set.

BigDog, HUSTLER

Bar Blade, Blade Bar, High Lift Bar Blade,
