BLADE HIGH LIFT, 18.50" -H-F-CW CUT SIDE DISCHARGE (pack of 10s)

Genuine BigDog & HUSTLER 54" Cut Side Discharge High Lift Bar Blade

Genuine Hustler and BigDog high lift bar blade. Fitted as a production line bladeon 54" cut side discharge HUSTLER FasTrak and Fastrak SDX. Fitted as a servicereplacement blade on several other models listed below where a high lift blade isrequired. Blade Lift refers to the ability of a blade to provide vacuum to liftgrass so that it can be cut uniformly. More blade lift also contributes to removingdebris out of the grass, clearing debris out of the deck and throwing the grassfurther in side discharge mode. In some conditions, more blade lift can result incausing debris to build up under the deck, while in other conditions, the oppositeis true. Blade "Lift" can be measured from the bottom side of the blade to thehighest point of the blade sail. The high Lift Blade (H) is the standard blade formany deep decks. A high lift blade provides more vacuum for better finishedapperance. Blade lift for this blade measures 1.09" / 27.68 mm).

BigDog 606251HUSTLER 606251

0.63"

16.002 mm

54" cut

1372 mm

137.2 cm

18.50"

469.9 mm

0.203"

5.156 mm

2 1/2"

63.5 mm

Flute/sail height 1.09"

Flute/sail height 27.68 mm

Round

54" (1372 mm) cut BigDog Stout (models BDU935510EX and BDU937656EX) side dischargezero turn radius (ZTR) models.

3

54" (1372 mm) cut HUSTLER FasTrak (models HU938712EX and HU940353EX), FasTrak SDX(models HU938787EX and HU940429EX) and Raptor XDX (model HU941500EX) side dischargezero turn radius (ZTR) models.

3

High lift, flat blade, clockwise rotation (flute/sail height 1.09"/ 27.68 mm).

1

Please call our friendly sales team if any assistance or further information isrequired.

All blade bars are sold as singles, order the quantity required to make up a set.

BigDog, HUSTLER

Bar Blade, Blade Bar, High Lift Bar Blade,
