BLADE CATCHING, 17.86"-CAT-F-CW 36" & 52" CUT SIDE DISCHARGE (Sold per blade)

Genuine BigDog & HUSTLER 36" & 52" Cut Catching Bar Blade

Genuine Hustler and BigDog catching bar blade. Fitted as a service replacementblade on the models listed below where a catching blade is required. Blade Liftrefers to the ability of a blade to provide vacuum to lift grass so that it can becut uniformly. More blade lift also contributes to removing debris out of thegrass, clearing debris out of the deck and throwing the grass further in sidedischarge mode. In some conditions, more blade lift can result in causing debris tobuild up under the deck, while in other conditions, the opposite is true. Blade"Lift" can be measured from the bottom side of the blade to the highest point ofthe blade sail. A Catching Blade ( C ) generates the energy required to transfergrass to bagging systems where there is no external blower. Blade lift for thisblade measures 1.50" (38.1 mm).

BigDog 603848HUSTLER 603848

0.63"

16.002 mm

36" & 52" cut

915 mm & 1320 mm

91.5 cm & 132 cm

17.86"

453.64 mm

0.203"

5.156 mm

3"

76.2 mm

1.50"

38.1 mm

Round

36" (915 mm) cut BigDog A Series (models BDU931337EX) side discharge zero turnradius (ZTR) models.

2

36" (915 mm) cut HUSTLER Raptor SD (models HU935262EX and HU938365EX) sidedischarge zero turn radius (ZTR) models.

2

52" (1320 mm) cut BigDog Alpha Series (models BDU932913EX and BDU939124EX) sidedischarge zero turn radius (ZTR) models.

3

52" (1320 mm) cut HUSTLER Raptor (models HU931899EX, HU938282EX and HU939116EX)side discharge zero turn radius (ZTR) models.

3

Catching, flat blade, clockwise rotation (flute/sail height 1.50"/ 38.1 mm).

1

Please call our friendly sales team if any assistance or further information isrequired.

All blade bars are sold as singles, order the quantity required to make up a set.
